Description
Introducing the QuicRun 4274 SL G2 from Hobbywing.
Perfectly compatible with Hobbywing EZRUN MAX8 G2S ESC
The motor perfectly paired with the EZRUN MAX8 G2S ESC. It is equipped with a standard 6.5mm male connector (low IR) to support plug and play on the system.
Increased efficiency and reduced temperature rise
The motor has ultra-high efficiency, resulting in extremely low temperature buildup. Compared with motors of the same specifications and under the same test conditions, internal temperatures are lowered by approximately 20°C external temperatures are lowered by approximately 12°C
Asymmetrical bearing design, increases reliability and efficiency
The front end of the motor uses a precise large bearing structure to improve load-carrying performance; the rear end uses a precise small bearing structure with lower resistance; Having asymmetrical bearings increases reliability and efficiency.
Silicone outlet, easier wiring
The motor uses 10AWG silicone wire. Compared with straight out high-hardness enameled wire, the new wiring is simple and is aesthetically pleasing.
Solid materials, quality assurance
At Hobbywing, we take pride in our manufacturing process and the high-quality materials we use to build a motor that offer exceptional durability, maximum performance and consistency.
Note: The highest support is 55000RPM
Good linearity and low loss
The rotor is precisely balanced to reduce motor vibration and energy loss. It also further ensures good linearity of the overall powerband.
Blind hole thread design, highly compatible
The front end of the motor adopts a blind hole thread design to prevent the motor from being damaged due to long mounting screws; it also takes into account of M3 or M4 screw installation, which is compatible with various installation requirements.
Modular design, easy to disassemble and maintain
The motor adopts a modular structure design. It makes daily cleaning and maintenance convenient, effectively prolonging the life-span of the motor and maintaining the working efficiency of the motor.
Specification
- Scale - 1/8th on-road/rally or 1/10th monster truck
- Brushed/Brushless - BL
- Sensored/Sensorless - SL
- Pole Count - 4
- KV Rating - 2600KV
- LiPo - 3-4s
- No-load Current(A) - 6.1A
- O.D. (mm) - 42
- Length (mm) - 68.4
- Shaft Diameter (mm) - 5
- Connectors 6.5mm male
- Wire Black-10AWG-200MM*3
- Weight (g) - 417g
- Front Bearing - D16*D5*T5
- Rear Bearing - D13*D5*T4
- Timing - Fixed
- Applications - 1/8th on-road/rally -1/10th Monster Truck
